Manufactured by the market leader Harvey Water Softeners of Woking, Surrey, the Big Blue Twin Cylinder tank Non-Electric Water Softener is a light-commercial softener designed for larger homes, small hotels and B&B's and small businesses.

The Big Blue provides a constant supply of soft water, 24/7 without the need for programming.

Working in conjunction with larger pipework up to 28mm (1inch), the Harvey Big Blue Water Softener is a more eco-friendly solution providing you with purified water every day.

Energy efficient - the Big Blue is powered by water and is efficient in salt and water usage with no costly annual servicing.

The large capacity of the Big Blue means it can produce a large amount of soft water and cope with fluctuations in water demand.

Benefits

 Daily capacity - unlimited soft water
Regeneration water use - 50-litres
To meet the needs of a 1-20 person property.
Suitable for properties with multiple bathrooms on a direct water system.
Compact design (size: 670H x 610W x 600D mm).
A full range of installation kits available to suit all pipework.
 High quality British design and manufacture
As easy to install as a washing machine.
 Should be fitted as close as possible to the incoming cold water supply.
 No power supply required (meter controlled).
 Always use standard tablet water softener salt.
 Water pressure: 1-8 bar.
 Flow rate: 10 to 80 l/min.
 Inlet: ¾" bsp male + 1" adaptor.
 Outlet: ¾" bsp male + 1" adaptor.
Salt storage capacity: 65kg Tablet Salt
27 mins regeneration time

Dimensions
Height - 670mm
Width - 610mm
Depth - 600mm

WARRANTY - 5 years parts & labour


WHICH INSTALLATION KIT?

It is important that you select the correct installation kit to suit your pipework and hot water system in your property. This avoids any chance of the incorrect installation kit from restricting through the water softener and therefore within your property.

In U.K homes, generally there are three sizes of pipework measurements, all are the diameter across the pipe and they are 15mm, 22mm & 28mm. Generally Water softeners are installed near where the water enters your property, so please measure the pipework above the main isolation valve.

If you have 15mm pipework and a conventional gravity fed, or indirect, system which has a cold water tank in the loft space and hot water cylinder, then our standard  15mm installation kit would be suitable. We offer two lengths of flexible hose to go between your fixed pipework and the water softener, either 1000mm or 1500mm long.

If you are still on 15 mm pipework but have a combination boiler, or direct type system, then you are better to go with the 15mm High Flow installation kit. This has the benefit of using uprated fittings and connection hoses and ensures that you get full flow through everything and therefore get no restriction on flow to and from  your water softener. We offer two lengths of flexible hose to go between your fixed pipework and the water softener, either 800mm or 1000mm long.

If you have 22mm pipework, then the best choice is one of our 22mm install kits. This is found in nearly all houses built since year 2000 and are generally used on feeding mains fed unvented hot water systems. We offer these kits with either 800mm or 1000mm long flexible connection hoses.

In larger properties then we offer a 28mm installation kit for use with suitable Water softeners where the connection pipework is 28mm diameter. We offer two lengths of flexible hose to go between your fixed pipework and the water softener, either 800mm or 1000mm long.

If you are unsure about any of the install kit choices, then please call us on 01403 701970 or email for clarification.

Harvey Big Blue Non-Electric Water Softener

Harvey
In Stock
A light-commercial softener designed for larger homes, small hotels and B&B's and small businesses.
£ 1,995.00
£ 1,234.50
-38%
